| भाग क्रमांक | LTN133AT09-G02 |
| ब्रँड | Samsung |
| आकार | 13.3 |
| अर्ज | NBPC |
| ठराव | 1280×800 |
| रचना | LCM |
| चमक | 275 |
| CR | 700:1 |
| रंग | 262K |
| बॅकलाइट | WLED |
| इंटरफेस | LVDS |
| पॅनेल ब्रँड | SAMSUNG |
| पॅनेल मॉडेल | LTN133AT09-G02 |
| पॅनेल प्रकार | a-Si TFT-LCD , LCM |
| पॅनेल आकार | 13.3 inch |
| ठराव | 1280(RGB)×800 , WXGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 286.08×178.8 mm |
| बाह्यरेखा | 297.15×192.15×3.68 mm |
| आकार शैली | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| पृष्ठभाग | Glare (Haze 0%), Hard coating (3H) |
| चमक | 275 cd/m² (Typ.) |
| कॉन्ट्रास्ट रेशो | 700:1 (Typ.) |
| रंग प्रदर्शित करा | 262K (6-bit), CIE193145% |
| प्रतिसाद वेळ | 16 (Typ.)(Tr+Td) |
| पाहण्याचा कोन | 70/70/55/60 (Typ.)(CR≥10)(L/R/U/D) |
| वारंवारता | 60Hz |
| दिवा प्रकार | 9S6PWLEDWithout Driver |
| सिग्नल इंटरफेस | LVDS (1 ch, 6-bit), 30 pins |
| इनपुट व्होल्टेज | 3.3V (Typ.) |
| अर्ज | NBPC |
