| भाग क्रमांक | LTN133AT23-001 |
| ब्रँड | Samsung |
| आकार | 13.3 |
| अर्ज | NBPC |
| ठराव | 1366×768 |
| रचना | LCM |
| चमक | 300 |
| CR | 220:1 |
| रंग | 262K |
| बॅकलाइट | WLED |
| इंटरफेस | LVDS |
| पॅनेल ब्रँड | SAMSUNG |
| पॅनेल मॉडेल | LTN133AT23-001 |
| पॅनेल प्रकार | a-Si TFT-LCD , LCM |
| पॅनेल आकार | 13.3 inch |
| ठराव | 1366(RGB)×768 , WXGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 293.42×164.97 mm |
| पृष्ठभाग | Antiglare (Haze 25%) |
| चमक | 300 cd/m² (Min.) |
| कॉन्ट्रास्ट रेशो | 220:1 (Typ.) |
| रंग प्रदर्शित करा | 262K (6-bit), CIE193145% |
| प्रतिसाद वेळ | 16 (Typ.)(Tr+Td) |
| पाहण्याचा कोन | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| वारंवारता | 60Hz |
| दिवा प्रकार | 8S4PWLEDEmbedded (LED Driver) |
| सिग्नल इंटरफेस | LVDS (1 ch, 6-bit), 40 pins |
| इनपुट व्होल्टेज | 3.3V (Typ.) |
| अर्ज | NBPC |
| LTN133AT07-G01 | Samsung | 13.3 | 1280×800 |
| LTN133AT09-W01 | Samsung | 13.3 | 1280×800 |
| LTN133AT13-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT14-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT16-L01 | Samsung | 13.3 | 1280×800 |
| LTN133AT17-W01 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-803 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-C01 | Samsung | 13.3 | 1366×768 |
| LTN133AT25-T01 | Samsung | 13.3 | 1366×768 |
| LTN133AT27-102 | Samsung | 13.3 | 1366×768 |
| B121EW10 V1 | AUO | 12.1 | 1280×800 |
| B156HW03 V0 | AUO | 15.6 | 1920×1080 |
| LP150X09-B5K8 | LG Display | 15.0 | 1024×768 |
| LTD121EXSS | TOSHIBA | 12.1 | 1280×800 |
| LTD121KX6B | TOSHIBA | 12.1 | 1280×800 |
| LTN141AT12-W03 | Samsung | 14.1 | 1280×800 |
| LTN154X1-L03 | Samsung | 15.4 | 1280×800 |
| LTN156AT02 | Samsung | 15.6 | 1366×768 |
| N140O6-L02 | Innolux | 14.0 | 1600×900 |
| VVX16T010J00 | Panasonic | 15.5 | 2880×1620 |
