| भाग क्रमांक | NL128102AC29-17 |
| ब्रँड | NLT |
| आकार | 19.0 |
| अर्ज | IA |
| ठराव | 1280×1024 |
| रचना | LCM |
| चमक | 800 |
| CR | 1000:1 |
| रंग | 16.7M |
| बॅकलाइट | WLED |
| इंटरफेस | LVDS |
| पॅनेल ब्रँड | NLT |
| पॅनेल मॉडेल | NL128102AC29-17 |
| पॅनेल प्रकार | a-Si TFT-LCD , LCM |
| पॅनेल आकार | 19.0 inch |
| ठराव | 1280(RGB)×1024 , SXGA |
| प्रदर्शन मोड | UA-SFT, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 376.32×301.056 mm |
| बाह्यरेखा | 396×324×18.5 mm |
| पृष्ठभाग | Antiglare, Hard coating (2H) |
| चमक | 800 cd/m² (Typ.) |
| कॉन्ट्रास्ट रेशो | 1000:1 (Typ.) |
| रंग प्रदर्शित करा | 16.7M (8-bit), CIE193172% |
| प्रतिसाद वेळ | 14/11 (Typ.)(Tr+Td) |
| पाहण्याचा कोन | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| वारंवारता | 60Hz |
| दिवा प्रकार | WLEDEmbedded (LED Driver) |
| सिग्नल इंटरफेस | LVDS (2 ch, 8-bit), 30 pins |
| इनपुट व्होल्टेज | 5.0V (Typ.) |
| अर्ज | IA |
