| भाग क्रमांक | N070ICN-GB1 |
| ब्रँड | Innolux |
| आकार | 7.0 |
| अर्ज | PAD |
| ठराव | 800×1280 |
| रचना | LCM |
| चमक | 300 |
| CR | 800:1 |
| रंग | 16.7M |
| बॅकलाइट | WLED |
| इंटरफेस | MIPI |
| पॅनेल ब्रँड | INNOLUX |
| पॅनेल मॉडेल | N070ICN-GB1 |
| पॅनेल प्रकार | a-Si TFT-LCD , LCM |
| पॅनेल आकार | 7.0 inch |
| ठराव | 800(RGB)×1280 , WXGA |
| प्रदर्शन मोड | IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 94.2×150.72 mm |
| बाह्यरेखा | 105.62×163.27×4.56 mm |
| पृष्ठभाग | Glare (Haze 0%), Hard coating (3H) |
| चमक | 300 cd/m² (Typ.) |
| कॉन्ट्रास्ट रेशो | 800:1 (Typ.) |
| रंग प्रदर्शित करा | 16.7M (8-bit), CIE193160% |
| प्रतिसाद वेळ | 11/9 (Typ.)(Tr/Td) |
| पाहण्याचा कोन | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| वारंवारता | 60Hz |
| दिवा प्रकार | 3S6PWLEDWithout Driver |
| सिग्नल इंटरफेस | MIPI (4 data lanes), 31 pins |
| इनपुट व्होल्टेज | 1.8/3.3V (Typ.)(VDDI/VCI) |
| अर्ज | PAD |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
| C070VW04 VB | AUO | 7.0 | 800×480 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| BP070WX1-300 | BOE | 7.0 | 800×1280 |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| HV121X03-100 | HYDIS | 12.1 | 1024×768 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| NDS0708001280-31 | SEBO | 7.0 | 800×1280 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
