| भाग क्रमांक | LH550WF2-SD03 |
| ब्रँड | LG Display |
| आकार | 5.5 |
| अर्ज | MPH |
| ठराव | 1080×1920 |
| रचना | LCM |
| चमक | 460 |
| CR | 1000:1 |
| रंग | 16.7M |
| बॅकलाइट | WLED |
| इंटरफेस | MIPI |
| पॅनेल ब्रँड | LG Display |
| पॅनेल मॉडेल | LH550WF2-SD03 |
| पॅनेल प्रकार | LTPS TFT-LCD , LCM |
| पॅनेल आकार | 5.5 inch |
| ठराव | 1080(RGB)×1920 , FHD |
| प्रदर्शन मोड | AH3-IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 68.04×120.96 mm |
| बाह्यरेखा | 70.94×128.01×1.55 mm |
| पृष्ठभाग | |
| चमक | 460 cd/m² (Typ.) |
| कॉन्ट्रास्ट रेशो | 1000:1 (Typ.) |
| रंग प्रदर्शित करा | 16.7M (8-bit), CIE193170% |
| प्रतिसाद वेळ | 25 (Typ.)(Tr+Td) |
| पाहण्याचा कोन | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| वारंवारता | 60Hz |
| दिवा प्रकार | 6S2PWLEDWithout Driver |
| सिग्नल इंटरफेस | MIPI (4 data lanes), 50 pins |
| इनपुट व्होल्टेज | 1.8/5.0/-5.0V (Typ.)(VDD/VAN/VPG) |
| अर्ज | MPH |
