| भाग क्रमांक | EJ101IA-01C |
| ब्रँड | Innolux |
| आकार | 10.1 |
| अर्ज | PAD |
| ठराव | 1280×800 |
| रचना | LCM |
| चमक | 400 |
| CR | 800:1 |
| रंग | 16.7M |
| बॅकलाइट | WLED |
| इंटरफेस | LVDS |
| पॅनेल ब्रँड | CHIMEI INNOLUX |
| पॅनेल मॉडेल | EJ101IA-01C |
| पॅनेल प्रकार | a-Si TFT-LCD , LCM |
| पॅनेल आकार | 10.1 inch |
| ठराव | 1280(RGB)×800 , WXGA |
| प्रदर्शन मोड | IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 216.96×135.6 mm |
| बाह्यरेखा | 228.96×148.5×4.6 mm |
| पृष्ठभाग | Hard coating, Antireflection |
| चमक | 400 cd/m² (Typ.) |
| कॉन्ट्रास्ट रेशो | 800:1 (Typ.) |
| रंग प्रदर्शित करा | 16.7M (8-bit), CIE193150% |
| प्रतिसाद वेळ | 10/15 (Typ.)(Tr/Td) |
| पाहण्याचा कोन | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| वारंवारता | 60Hz |
| दिवा प्रकार | 6S6PWLEDEmbedded (LED Driver) |
| सिग्नल इंटरफेस | LVDS (1 ch, 8-bit), 45 pins |
| इनपुट व्होल्टेज | 3.3V (Typ.) |
| अर्ज | PAD |
