| भाग क्रमांक | BT140GW01 V.0 |
| ब्रँड | Innolux |
| आकार | 14.0 |
| अर्ज | NBPC |
| ठराव | 1366×768 |
| रचना | LCM |
| चमक | 220 |
| CR | 600:1 |
| रंग | 262K |
| बॅकलाइट | WLED |
| इंटरफेस | LVDS |
| पॅनेल ब्रँड | INNOLUX |
| पॅनेल मॉडेल | BT140GW01 V.0 |
| पॅनेल प्रकार | a-Si TFT-LCD , LCM |
| पॅनेल आकार | 14.0 inch |
| ठराव | 1366(RGB)×768 , WXGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 309.399×173.952 mm |
| बाह्यरेखा | 323.5×192×5.2 mm |
| आकार शैली | Wedge (PCBA Bent, Depth ≥5.2mm) |
| पृष्ठभाग | Glare (Haze 0%), Hard coating (3H) |
| चमक | 220 cd/m² (Typ.) |
| कॉन्ट्रास्ट रेशो | 600:1 (Typ.) |
| रंग प्रदर्शित करा | 262K (6-bit), CIE193160% |
| प्रतिसाद वेळ | 8 (Typ.)(Tr+Td) |
| पाहण्याचा कोन | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| वारंवारता | 60Hz |
| दिवा प्रकार | WLEDEmbedded (LED Driver) |
| सिग्नल इंटरफेस | LVDS (1 ch, 6-bit), 40 pins |
| इनपुट व्होल्टेज | 3.3V (Typ.) |
| अर्ज | NBPC |
